BlackmagicDesign Blackmagic Media Player 10G BDLKULSTMP010G
【ご確認下さい】
BlackmagicDesign社の製品はシステム構築最低要件をメーカーサポートページにてご確認いただけます。
ブラックマジックデザインサポートページ
1
1
1
1
1
1
270Mb, 1.5G, 3G, 6G, 12G.
1
1
2 channels of professional balanced analog audio with 3-pin XLR connectors.
1 x 6.35 mm headphone jack.
16 Channels embedded in SD/HD/2K/UHD/4K.
16 Channels embedded in SD/HD/2K/UHD/4K.
8 Channels embedded in SD/HD/UHD/4K.
8 Channels embedded in SD/HD/UHD/4K.
1 x Sony™ compatible RS-422 deck control input port.
1 x USB‑C 3.1 Gen 1 (up to 5 Gb/s).
2 x Thunderbolt™ 3 (Mac OS, Windows and Linux)
1 x USB‑C for keyboard, mouse and other USB devices
1 x 10Gb/s RJ‑45 connector supporting 1000/10G BASE‑T.
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4.
Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Firmware built into software driver. Software driver loads upgrades at system start or via updater software.
DaVinci Resolve
Fusion
720p50、720p59.94、720p60
1080i50、1080i59.94、1080i60
1080p23.98、1080p24、1080p25、1080p29.97、1080p30、1080p50、1080p59.94、1080p60
2Kp23.98 DCI、2Kp24 DCI、2Kp25 DCI、2Kp29.97 DCI、2Kp30 DCI、2Kp50 DCI、2Kp59.94 DCI、2Kp60 DCI
2KPsF23.98 DCI、2KPsF24 DCI、2KPsF25 DCI、2KPsF29.97 DCI、2KPsF30 DCI
2160p23.98、2160p24、2160p25、2160p29.97、2160p30、2160p50、2160p59.94、2160p60
4Kp23.98 DCI、4Kp24 DCI、4Kp25 DCI、4Kp29.97 DCI、4Kp30 DCI、4Kp50 DCI、4Kp59.94 DCI、4Kp60 DCI
SMPTE 259M、SMPTE 292M、SMPTE 292M、SMPTE 424M、SMPTE 425M level AおよびB、SMPTE 2081-1、SMPTE 2081-10、SMPTE 2082-1、SMPTE 2082-10、SMPTE 2084およびSMPTE ST2108-1.
RP 188/SMPTE 12M-2 and closed captioning.
SDI video connections are switchable between SD/HD/2K/UHD and 4K.
Television standard sample rate of 48 kHz and 24-bit.
4:2:2、4:4:4
8, 10, 12-bit RGB 4:4:4 in modes up to 4Kp30 and8, 10-bit YUV 4:2:2 in all modes.
REC 601、REC 709およびREC 2020
HDR static metadata packing, HLG and PQ transfer characteristics.
525i59.94 NTSC、625i50 PAL
720p50、720p59.94、720p60
1080i50、1080i59.94、1080i60
1080p23.98、1080p24、1080p25、1080p29.97、1080p30、1080p50、1080p59.94、1080p60
2160p23.98、2160p24、2160p25、2160p29.97、2160p30、2160p50、2160p59.94、2160p60
4Kp23.98 DCI、4Kp24 DCI、4Kp25 DCI、4Kp29.97 DCI、4Kp30 DCI、4Kp50 DCI、4Kp59.94 DCI、4Kp60 DCI
Television standard sample rate of 48 kHz and 24-bit.
4:4:4、4:2:2および4:2:0
8, 10 and 12-bit
REC 601、REC 709およびREC 2020
HDR static metadata packing, HLG and PQ transfer characteristics.
HDMI 2.0b supports Deep Color and HDR. Automatically configures to connected display.
HDMI video connections are switchable between SD/HD/UHD and 4K.
v210 (10 bit YUV), 2vuy (8 bit YUV), ARGB, BGRA (8 bit RGB), r210 (10 bit RGB), Ay10 (10 bit YUVA), R12B, R12L (12 bit RGB).
6 buttons, spin knob and 2.2 inch color display for menu and settings. Front speaker on/off button.
RS-422 deck control input for remote control of software. Also supports Advanced Media Protocol.
Half rack unit width, 1 rack unit height.
Mac 13.0 Ventura
Mac 14.0 Sonoma以降のバージョン
Windows 10 64-bit
Windows 11
1 x Internal 100 - 240V AC 50/60Hz with IEC C14 socket.
TBA
5° to 40° C (41° to 104° F)
-20° to 45° C (-4° to 113° F)
0% to 90% non‑condensing
3 Year Limited Manufacturer's Warranty.
